Manufacturer Line Number: 781
Date Of Manufacture: February 1, 2000
Total Aircraft Time (Flight Hours): 32637:56
Total Aircraft Cycles Since New: 6185
Airframe Flight Hours Flown during month: 20:11
Airframe Cycles/Landings during month: 5
Time Remaining to A-Check: 43 Days
Engine Model:
GENERAL ELECTRIC CF6-80C2-B6F Left Right
S/N: 704-813 704-812
Date of Manufacture 22 Feb 1999
Original Position Left Right
Actual Position Left Right
Total Time SNEW 32529:56 31525:56
Total Cycles SNEW 6833 6726
Flight Hrs. during month 20:11 20:11
Cycles during month 5 5
Time Since Last Borescope 153 Cycles 153 Cycles
Time Until Next Borescope 47 Cycles 247 Cycles
APU Model:
HONEYWELL GTCP331-200
S/N: P-2346
Date of Manufacture: 1 Nov 1996
LANDING GEAR: NLG S/N: MC0277P0781
Time Since New 32637 Hours
Cycles Since New 6185
Brake Manufacturer: Allied Signal
Type: Carbon LH MLG S/N: T-10491
Time Since New 32637 Hours
Cycles Since New 6185
RH MLG S/N: T-10492
Time Since New 32637 Hours
Cycles Since New 6185
AVIONICS SYSTEMS:AUTO FLIGHT
MODEL or PART
QTY COMPONENT MANUFACTURER NUMBER
3 Flight Control Computer: Rockwell Collins 622-8757-106
1 Thrust Management Computer: General Electric 948E310G2
2 Rudder Ratio Module: Boeing 285T0014-104
6 Spoiler Control Module: Boeing 285T0012-201/-115
2 Stabilizer and Aileron Module: Boeing 285T0015-116
2 Yaw Damper Module: Boeing 285T0013-126
COMMUNICATIONS
MODEL or PART
QTY COMPONENT MANUFACTURER NUMBER
1 PA Amplifier: Rockwell Collins 622-5342-101
2 HF Transceiver: Rockwell Collins 622-5272-120
3 VHF COM Transceiver: Rockwell Collins 822-1047-003
1 Cockpit Voice Recorder: L3 S200-0012-00
1 CD player (Audio): Matsushita RDAX7095-01
Tape Reproducer (Video) BE Avionics 2002-03-012 (6ea)
6 & 2 Entertainment: Matsushita RDAV1115 (2ea)
1 SELCAL Decoder: Team SC2253AD01
1 ACARS Management Unit: Honeywell 965-0758-001
1 Printer: Miltope 706300-211
INDICATING AND RECORDING
QTY COMPONENT MFG PART NUMBER
1 Flight Data Recorder (DFDR): Honeywell 980-4700-003
1 Digital Flight Data Acquisition Unit: Teledyne 2233000-45
3 Accelerometer: Honeywell 26000255-104
ENGINE INDICATING AND CREW ALERTING SYSTEM (EICAS)
1 EICAS Display Unit (Upper): Rockwell Collins 622-7999-003
1 EICAS Display Unit (Lower): Rockwell Collins 622-7999-003
2 EICAS Computer: Rockwell Collins 822-1033-100
1 Standby Engine Indicator: Smiths Ind. 402EED2-1
NAVIGATION
QTY COMPONENT MANUFACTURER PART NUMBER
1 Enhanced Ground Proximity Warning System (EGPWS):
Air Data Computer:
Honeywell
Honeywell
965-0976-003-222
4040800-906
2 Windshear System (via GPWS): YES
2 Weather Radar Transceiver: Rockwell Collins 622-5132-130
1 Traffic Alert and Collision
Avoidance System (TCAS)Computer: Honeywell 7517900-10003
2 Air Traffic Control (ATC/Mode S) System Transponder:
Rockwell Collins 622-7878-201
3 Inertial Reference Unit (IRU): Honeywell HG1050AE10/AD10
ELECTRONIC FLIGHT INSTRUMENT SYSTEM (EFIS):
2 Electronic Attitude Director Indicator (EADI): Rockwell
Collins 622-7998-003
Electronic Horizontal Situation 2 Indicator (EHSI) Rockwell
Collins 622-7999-003
2 EFIS Symbol Generators: Rockwell Collins 622-9436-101
RADIO NAVIGATION:
2 Distance Measuring Equipment (DME) Interrogators: Rockwell
Collins 622-4540-122
2 VHF VOR/Marker Beacon Receiver: Rockwell Collins
822-0726-120
3 ILS/GPS Multi Mode Receiver: Rockwell Collins 822-1152-002
3 Radio Altimeter Transceiver: TRT 9599-607-14939
2 Radio Distance Magnetic Indicator (RDMI): Rockwell Collins
622-5001-111
2 Automatic Direction Finder (ADF) 2 Receiver: Rockwell
Collins 622-5222-120
FLIGHT MANAGEMENT COMPUTER SYSTEM (FMCS):
2 Flight Management Computer: Honeywell 4052506-955
2 Control Display Unit (CDU): Honeywell 4058650-931
INTERIOR:
50 Passenger
Six (6) Lavatories
